Anyone with a fear of flying robots and giant claws may not want to hear what the maker of the U.S. military’s Predator drone has planned for the future. The military contractor General Atomics is working on transforming a huge cargo aircraft into a drone mothership that uses a mechanical arm to grab returning drones in midair. The drone mothership claw is part of a General Atomics proposal for the U.S. military’s “Gremlins” program that envisions manned aircraft deploying swarms of small drones for scouting missions. The program specifications laid out by the U.S. Defense Advanced Research Projects Agency (DARPA) call for enabling a C-130 transport aircraft to launch drones capable of carrying 60 pounds of payload on a 600 mile roundtrip journey, according to Breaking Defense. The drone must have enough fuel to also spend an hour hanging around above a target area. News of General Atomic’s plan for a drone mothership mechanical arm came from a Breaking Defense interview with Chris Pehrson, General Atomics VP for Strategic Development, during the Air Force Association’s Air, Space & Cyber Conference held from Sept. 19-21.

Apparently Pehrson compared the action of the arm grabbing a drone as “almost like a Transformer-type thing.”macdev drone dx special edition The U.S. military has been bullish on the futuristic idea of using drone swarms for a while. ar drone power edition avisA drone mothership aircraft with the ability to launch and retrieve such swarms could scout a much wider area with less danger to the human crew aboard the mothership. ar drone parrot director modeBut this gets tricky when DARPA wants the mothership to be able to retrieve the drones in midair.ar drone parrot caracteristicas Certain systems such as Insitu ScanEagle have been designed to allow ships at sea to recover drones. macdev drone dx bolt upgrade

In the ScanEagle’s case, the returning drone catches onto a cable strung vertically on the side of the ship. rc mq-9 reaper drone for saleBut retrieving a drone from a moving ship is considerably less difficult than retrieving a drone in midair from an aircraft. A more relevant example may come from the aerial refueling demonstrations between the Northrop Grumman X-47B drone and a manned tanker aircraft. That required the X-47B to match speeds and nuzzle up carefully to the tanker aircraft’s refueling arm. But the General Atomics demonstration with small drones may face greater challenges docking with a C-130 mothership’s mechanical arm because of the turbulence from the much larger aircraft. So it remains to be seen whether the U.S. military’s future drone mothership will deploy the claw or use other methods to retrieve the swarms of tiny gremlin drones. DARPA, DARPA Gremlins program, Defense Advanced Research Projects Agency, drones, flying robots, General Atomics, military drones, robots, uas, uav, unmanned autonomous systems, weapons & security

The two primary lifting gases used by airships have been hydrogen and helium. Hydrogen is the earth’s lightest element, and it can be obtained easily and inexpensively, but its flammability makes it unacceptable for manned airship operations. In addition to the famous Hindenburg disaster, dozens of hydrogen airships were destroyed by fire, and no American airship has been inflated with hydrogen since the crash of the U.S. Army airship Roma in 1922.  The use of hydrogen as a lifting gas for passenger airships was completely abandoned by the late 1930s. Helium’s non-flammable nature makes it the only practical lifting gas for manned lighter-than-air flight, but it is scarce and expensive, and the use of helium can reduce a rigid airship’s payload by more than half. While the use of helium presented obvious operational challenges, airships of sufficient size were able to operate effectively when inflated with helium. LZ-129 Hindenburg was designed to operate with helium and could have conducted transatlantic operations to North America, although with a much smaller payload, with helium as a lifting gas, and the U.S. Navy’s rigid airships were also able to fulfill their missions inflated with helium;

U.S.S. Akron and U.S.S. Macon served as airborne aircraft carriers, carrying embarked fixed-wing aircraft, using the heavier gas. Hydrogen and Helium: The Basics Hydrogen and Helium are the two lightest elements on the periodic table: The atomic weight of a helium atom (4.002) is approximately four times that of an individual hydrogen atom (1.007), but since gaseous hydrogen is a diatomic molecule containing two hydrogen atoms (H2), helium gas is only twice as heavy as hydrogen gas. The Relative Lifting Ability of Hydrogen and Helium Although helium weighs twice as much hydrogen, because each gas is so much lighter than air helium provides about 93% of hydrogen’s lift at full purity. In practical operation it is impossible to achieve or maintain 100% purity of either gas, reducing helium’s lifting ability to about 88% of the lift of hydrogen. The actual lifting ability of each gas varies with temperature, pressure, and humidity, and to take account of varying atmospheric conditions and gas impurities airship designers often conservatively estimated helium’s lift at 60 lbs per 1,000 cubic feet and hydrogen’s lift at 68 lbs per 1,000 cubic feet.

Relative lifting ability of 100% Hydrogen vs. Helium 60° F, Barometric Pressure 29.92″ Hg The Effect of Helium on Airship Range and Payload In actual use, because of physical realities and operational considerations, the use of helium can reduce an airship’s payload lift by almost half. Fixed Weight vs. Lifting Gas Much of an airship’s weight is fixed (the dead weight of the ship’s structure and engines, and required weight such as crew and ballast) so the entire effect of the reduced lift of helium is absorbed by the ship’s payload; a helium-inflated airship therefore has a much lower payload for passengers and freight, and a much shorter range (because it can carry less fuel), than a hydrogen-inflated airship of the same size. Operational factors further decrease the payload of a helium-inflated airship. As an airship rises its lifting gas expands, so an airship that begins a flight with its gas cells fully inflated must release gas as it climbs to keep the cells from bursting.

Because hydrogen is inexpensive and easy to manufacture, hydrogen airships usually began flights fully inflated to maximize payload and released hydrogen as they climbed. But since helium has always been a rare and expensive gas, helium airships began their flights only 90-95% inflated — thus reducing payload — to allow the gas cells to expand without the need to release valuable helium. Hydrogen and helium airships also had different means of compensating for the lost weight of fuel burned in flight. Hydrogen ships simply released inexpensive and easy-to-replace hydrogen, but helium-inflated ships required equipment to recover water from engine exhaust to compensate for the weight of burned fuel and avoid releasing valuable helium; the weight of this heavy equipment further reduced the payload available for fuel, passengers, and freight. Payload Effect of Helium versus Hydrogen LZ-126/U.S.S. Los Angeles gives a real world example of the difference between operating the same ship with helium versus hydrogen.

When the German-built LZ-126 flew from Germany to the United States for delivery to the U.S. Navy in 1924 it was inflated with hydrogen, and the ship made the flight from Friedrichshafen, Germany to Lakehurst, New Jersey — 5,006 miles — nonstop. When the United States Navy operated the same ship with helium, as U.S.S. Los Angeles, its range was limited to 3,925 statute miles and it could not have made the same transatlantic flight. And never again did the ship fly as long as it did on its delivery flight with hydrogen, which lasted 81 hours, 32 minutes; ZR-3’s longest flight with helium was a little over 48 hours. The following chart illustrates the dramatic reduction in payload between helium and hydrogen by comparing the actual payload from a Hindenburg flight across the South Atlantic using hydrogen with the same flight if the ship had used helium. Inflated with hydrogen, Hindenburg was able to carry 21,076 lbs of payload; if the ship had been inflated with helium it could not have made the flight at all.
