Its not really meant for someone's first drone as there is s .. The two-axis Tarot Brushless Gimbal uses cutting-edge gyroscope technology to ensure you get crisp, stable images from your 3DR drone. The T-2D automatically compensates for the slightest movement, enabling you to capture rock steady video even in windy weather. Designed to accommodate the GoPro HERO 3, the T-2D Brushless Gimbal you get from 3DR is customized: pre-wired, pre-calibrated and configured to work with your 3DR copter. The T-2D offers manual camera control from your controller's Tilt knob, but the model you get from 3DR is also specially configured to allow the autopilot to control the camera automatically, which is critical to using applications like 3PV Follow Me mode on IRIS+. This T-2D ships pre-assembled by 3DR, and includes the mounting plate and hardware for our 2014 Quad, Y6, and X8. Mounting plate to mount the gimbal to 2014 Quad, Y6, and X8 Tarot brushless gimbal with IRIS and IRIS+ mounting plate– comes pre-assembled and pre-configured to work with your copter's RC for in-flight camera control

IRIS and IRIS+ mounting hardware Documentation and setup instructions Support GoPro HERO3 video auxiliary output (cable sold separately) Supply voltage polarity protection and voltage compensation Motor drive end short-circuit protection Sensitivity parameter adjustment and software 3D pose show through PC connection Adjustable rocker rate mode and position mode Supported receiver type : conventional receiver, S-BUS receiver, DSM2/DSMJ/DSMX receiver Support for remote devices : PPM/PCM/2.4G Working voltage: DC 7.4V ~ 14.8V (Recommended 12V, three lithium battery) Working current: 200 mA-500 mA (power supply voltage and the motor related) Working environment temperature: -15 ℃ ~ 65 ℃ Processor: Dual 32-bit high-speed ARM core processor Sensor: Three axis MEMS gyroscope and MEMS accelerometers Maximum angular rate : 2000 ° / sec Control frequency: 2000 Hz Motor drive frequency: 20 kHz (no noise smoothing driven)

Control accuracy : 0.1 ° (Pixel Grade) Control angle range : -45 ° ~ 45 ° (roll), -135 ° ~ 90 ° (tilt) Pose solver algorithms : PTZ dedicated brushless motor decoupled EKF algorithm Shooting equipment : GoPro HERO3 Weight without camera : 200 gar drone 2 with gopro Battery usage: The Tarot gimbal should be powered by a 2S or 3S LiPo battery only. where to buy dji droneIf you plan to use 4S, please use a voltage regulator to ensure the voltage stays within safe operating limits. ar drone 2 blackberry3DR RTF Quad, Y6, and X8 include a voltage regular to allow use of 4S batteries with the Tarot gimbal.ar drone gps qgroundcontrol

Note: Tarot gimbal does not include the GoPro camera. The mounting plate is compatible with IRIS+, X8+, 2014 Quad, Y6, and X8 only and does not attach to 2013 copter models. Assembly required to connect to Quad, Y6, and X8: assembly requires 1.5 mm and 2 mm hex keys (not included). ar drone 3 kopenIRIS+ includes a set of tall legs to use with the Tarot Gimbal. best buy parrot droneUsers with an original-edition IRIS will need to purchase a set of tall legs to use the gimbal. Export Control Classification Number: EAR99Tarot FY650 Sport - A Portable size Quadcopter with Motorized Landing Gear This is Tarot's only Quadcopter frame, 650 size, came with Motorized Landing Gear and it takes maximum 15" propeller. The Tarot FY650 Sport has a lot in common with the bigger Tarot FY680-Pro (it has Six rotors), both have a Carbon Fiber Deck and a Integrated PCB Board, user can solder the ESC's power cable directly onto this PCB board and save a lot of heavy and messy cables.

The movable battery mount is also a good feature to balance the best C.G., because when you put a Tarot T-2D gimbal in the front of the drone, you need to off-set the weight with battery. The best of all is the Motorized Landing Gear, they connected to a Controller (included) and through a switch on your RC transmitter, you can retract and deploy the legs, so you will not see the legs in your Video anymore, this is a nice touch as the Motorized Landing Gear usually is "DIY" item, now Tarot includes them in the package. The Tarot FY650 Sport airframe is versatile, you can put small but high speed motors and smaller props on it to become an agile GoPro Camera platform, or use with big motors and props on it to be a long flight time platform, it's a great choice for you in Price and Performance for shooting beautiful scenery or interesting footage for YouTube. We recommend 4S 14.8V, Tarot 4006 620kv and 13" prop, or even more powerful config like 6S 22.2V Li-Po, Tarot 4008 380kv motor 13" propeller, this can carry payload up to 1kg to 1.3kg, that means GoPro and similar size camera are no problem.

Remember that if you put the camera in front, please adjust the battery's position at the rear to have best C.G. Great all around drone You can put a lot of different gadgets on the drone, for lighter payload you can use lighter and cheaper config like small motors and battery, if you want to go big, just increase the size of the motor and props, we like this FY650 Sport. Came with the package, 100% made by Tarot, fully integrated with the FY650 Sport Airframe. Retract and Deploy with a flip of a switch The two landing gears connect to a controller, and connect the controller to the RC receiver. Four rotor drones will have longer flight time, but less payload capacity Two motor less then Hexacopter, that means less energy consumption and fly longer. The new designed Integrated PCB Upper Deck The Tarot FY650 Sport has a PCB Upper Deck and Carbon Fiber Lower Deck. You can solder the ESC's power directly onto the PCB Upper Deck, no need to handle a bunch of power cables, much clean layout in the drone.

The soldering points on the PCB Board This is the PCB Board of the FY680 Pro, very similar to the FY650 Sport. Light weight and easy to adjust motor mount Support motor up to 45mm Dia., with 16mm, 19mm, 25mm and 27.7mm hole spacing. Came with Mounting Rail and Movable Battery Mount No need to spend money for the mounting rail. It is 60mm apart, you can put T-2D Gimbal on it and move that battery position for best C.G. A Portable 650 Size Hexacopter Frame Easy transportation is very important, especially when you try to put it in the car by yourself... Fold it up, it's very portable It's foldable, easy to put in the back seat of your car. - Frame weight : 750g - Arms diameter : 16mm - Drone dia : 650mm - Center body dimension : 190 x 200 x 2.0mm - Mount mounting hole : 16mm hole x 2 / 19mm hole x 2 / 25mm hole x 4 / 28mm hole x 3 - Drone's weight (everything it needs to fly) : around 2.3kg - Payload (it can carry) : 1~1.3kg

Our Flight Reference : - Battery Supply : One 4S 14.8V 5500mah for 13 minutes - Motor : Tarot 4006 620kv Motor - ESC : Hobbywing Platinum 30A-OPTO - Propeller : Tarot 1355 Carbon Propellers - Carrying : Tarot T-2D Brushless Motor Gimbal, TS352 FPV Transmitter, GoPro Hero 3+ (They weight about 700g) 1. 1 X Tarot 650 Sport Airframe and Motorized Landing Gear 2. 1 X Controller for the Landing Gears 3. 1 X Manual with English 4. Battery Velcro Tape This is Airframe only! You need to put many electronics on it yourself, namely Motors, ESC, Flight Controller, FPV, Radio Controller, Camera Gimbal and Propellers, they are NOT easy stuff for beginners, so we recommend this airframe for those who can solder stuff and willing to put things together. This is a professional thing for movie grade video shooting, not a toy!! What you'll need to build this FY650 Sport Quadcopter? You see this is the FY650 Sport Frame only, you'll need the right electronics to build this, these are the items :

4 X Brushless motors (Recommended 50mm diameter class) 2 X 13" Clowckwise Propellers 2 X 13" Counter-Clowckwise Propellers 4 X 40A ESC 1 X Flight Controller w/ GPS function 1 X Radio Controller 1 X 14.8V 5500mah battery 1 X 4S Li-Po battery charger 1 X FPV System (optional) 1 X DJI iOSD Mini for Flight Data display (optional) 1 X Tarot Camera Gimbal (for GoPro) (optional) Pick the following items to build a Combo Kit! Having trouble of what to choose to build the drone? Don't worry, Helipal has chosen the following items for this frame so you can enjoy building this outstanding drone with the right items out of box. Get it now for USD $269.90 only! No, I don't need it1 X Storm 14.8V 5500mah 35C Battery (+USD $89.00)2 X Storm 14.8V 5500mah 35C Battery (+USD $179.00) No, I don't need it1 X SKYRC E4 Charger (+USD $25.90)1 X SKYRC Mini B6 Charger w/ 5A Power Supply (+USD $66.80) No, I don't need it1 X Multi-rotors Wire Pack (LE-0089A) (+USD $39.00)

No, I don't need it1 X Tarot T-2D Brushless Motor Gimbal for GoPro (+USD $149.00)1 X DJI H3-3D 3-Axis Gimbal for GoPro (+USD $399.00) No, I don't need it4 X Hobbywing XRotor 40A-OPTO ESC (+USD $74.00) No, I don't need it1 X DJI NAZA Lite Flight Controller (+USD $199.00)1 X DJI NAZA V2 Flight Controller (+USD $299.00)1 X DJI WooKong-M Flight Controller (+USD $999.00)1 X DJI A2 Flight Controller (+USD $1,299.00)1 X DJI A2 Flight Controller + iOSD MK II (+USD $1,399.00)1 X DJI A2 Flight Controller + iOSD MK II + Ground Station (+USD $1,599.00) No, I don't need it4 X Tarot 4006 620kv High Power Brushless Motors (+USD $139.00) No, I don't need it2 X Tarot 1355 Carbon Fiber Propellers (CW + CCW / pack) (+USD $34.00) No, I don't need it1 X DJI E800 Propulsion System (Incl. ESC, Motor & Propeller) (+USD $319.00) No, I don't need it1 X RadioLink AT9 Radio + R9D Receiver (+USD $119.00)1 X Walkera DEVO 7 Radio + RX701 Receiver (+USD $99.00)1 X Walkera DEVO 10 Radio + RX1002 Receiver (+USD $149.00)1 X Walkera DEVO F12E Radio + RX1202 Receiver (+USD $299.00)1 X Futaba 10J Radio + R3008SB Receiver (+USD $349.00)1 X Futaba 8FG Radio + R6808SB Receiver (+USD $469.00)1 X Futaba 14SG Radio + R7008SB Receiver (+USD $599.00)
