parrot ar drone without iphone
In my parrot ar.drone its just showing red light in all four corners and is not creating wifi hotspot to connect with remote. if any one could help me with this solving. Try to fully charge the battery. Once you have done this on the AR Drone push the un-pair button then push the 'reset' button and place the AR Drone on a flat level surface and unplug the battery. On the iPod/device go to the WiFi menu tap on the AR Drone and select 'Forget this device'. Reconnect the battery on the AR Drone and wait for the leds to go green. Put your iPod into Airplane mode, switch on the WiFi and try to reconnect to the AR Drone. If the led's on your AR Drone are green and you are still unable to connect can you try resetting your iPod/device . You might have it on access-point mode, which is for Android users like me, i had the same problem and turned out it was on Ad-hoc mode, which is for Apple users. Hold down the unpair button for 5 sec. The LEDs flash red when access-point mode is switched to ad-hoc mode.
Just reset the drone :)
black ops 2 apocalypse droneThe AR Drone, a fururistic ‘quadrocopter’ that can be controlled via video-link to an iPhone or iPod touch, will start shipping tomorrow.
ar drone motor weight The space-age gadget is controlled by a handheld device using WiFi networking technology and works both indoors and out. The craft streams a live feed back to the user at 15 fps from a front-facing camera which allows the craft to be controlled from a pilots-eye view. A second ground-facing camera mounted on the underbelly of the drone captures the action at 60fps. Data from the second camera helps the internal guidance systems deliver a smooth flying experience. But the developers, Parrot S.A, haven’t stopped there; perhaps the coolest feature of the AR Drone is that it allows multiple units to go head-to-head in an augmented reality game, giving the drones the ability to fire virtual lasers at each other (see the video, below).
Anyone who has tried to pilot a regular remote-controlled helicopter will know how difficult they are to fly and also how easy they are to damage. Sporting four rotors instead of two, quadrocopters are significantly more stable in flight than their twin-rotor cousins. The AR Drone boasts sophisticated software, running on an embedded Linux OS on a 468mhz ARM processor, to process and react to in-flight information coming from the 3-axis accelerometer, multiple gyrometers, ultrasound altimeter and the vertical ground-facing camera. The marketing guys at Parrot claim that all this guidance technology means that even a child can fly the AR Drone. Writing on the product’s official website, the makers claim: Thanks to its Microelectromechanical systems (MEMS), Digital Signal Processor (DSP), Inertial measurement unit (IMU) and sensors, the Parrot AR.DRONE turns complex fly patterns into an easy-to-pilot system. Children will pilot AR.DRONE instinctively, using the iPhone, without any learning curve.
This allows for an incredible fly experience and acrobatics. The aircraft has also been built with durability in mind; it sports a protective frame that shields the delicate rotors from knocks and bumps. , the craft is built to withstand some moderately rough treatment: Constructed of carbon fiber tubes and PA66 plastic, the AR.Drone is meant to stand up to abuse. PA66 plastic is known for being hard, rigid, and resistant to abrasions, while carbon fiber is one of the strongest and lightest materials on the planet. Little chance of breaking the structure of the AR.Drone during normal use. According to the technical specs, users can expect to get only around 12 minutes of flying time from the 3-cell lithium-polymer battery, which will then take approximately 90 minutes to recharge. That doesn’t sound much, although presumably enthusiastic users could purchase multiple batteries and swap them out as they drain. Perhaps the coolest thing about the AR Drone from a geek’s perspective is the prospect of building your own games and controller software for the device.
The team at Parrot are actively encouraging developers to build cool augmented reality games and custom controllers for the device using their SDK (to register as a developer, go to the ARDrone developer page). Using the AR Drone API, developers can build software to control the AR Drone from any Wi-Fi capable device. This should mean that controller software and potentially some pretty cool games for Android-based mobile phones, PCs and many other platforms and devices should follow quickly after the launch of the device. The AR Drone ships September 9th and is available for pre-order at Amazon for a hefty $299.99. Check it out at the Parrot AR Drone website Ultimate list of 30 camera drones sorted by price [Early 2017 Edition] Ultimate list of 30 camera drones sorted by p…Drone is a $300 toy. That's a lot of money to drop on something you'll fly around your home or at the park. After playing with the hardware, however, that price is more than acceptable: there is a whole lot of technology crammed into that lightweight frame.
This is a quadrocopter with two cameras, an onboard computer running Linux, and the ability to play virtual games with real-world hardware. If you're into flying toys, playing with software, or simply finding new and novel uses for your iPhone, you'll find something to love here. Plus, this is a very effective platform for instilling terror and respect into your cats or small children. The value of such things cannot be overstated. The hulls slide onto the unit's base and attach via magnets, and can be swapped out in seconds. Both are made of lightweight styrofoam, and even after extensive testing and a few bad crashes we didn't break either. Parrot offers replacement parts and repair instructions on its site just in case anything goes wrong, meaning a bad crash isn't the end of the world. That's a very good thing, because this is a device that takes both skill and practice to pilot effectively. Don't worry about learning, though; the drone helps you along by stabilizing itself and adjusting its flying level without your direct help.
The bottom of the drone features an ultrasound altimeter so it knows how high it's flying and can keep its altitude steady. That means if you are flying over gentle hills or obstructions, it will bob up and down appropriately. The drone also comes with an accelerometer and two gyroscopes to keep things level and running smoothly. The brain powering the drone is a custom-built Linux system with a 468Mhz ARM9 processor, 128MB of memory, and a WiFi router that lets your iPhone connect with it. Parrot is not messing around here—this is a very smart toy. Flying is an interesting experience. You tap a virtual button on your iPhone, and the drone takes off and hovers. By placing your thumb on the left side of the screen you take over, allowing you to go forward and backward, and to strafe left and right. Move your thumb across the left side of the screen to control altitude, and turn to control yaw. It's somewhat intuitive, but you'll need some practice before you can do anything really crazy.
Video from the drone's front and bottom cameras is shown on your iPhone. If the propeller hits a solid object, power is cut to the engines and the drone falls to the Earth. If you're done flying you can tap the land button and the drone slowly eases to the ground. You can manually hit an emergency button on your iPhone to likewise cut power to the engines. You'll need to learn where the landing and emergency cut-off switches are quickly, since you're going to crash. I was warned to take it easy on my first few flights, and to stand directly behind the drone to make turning easy. When you tilt your iPhone forward the drone moves forward, but once you start turning the drone using the yaw control, you'll have to quickly acclimate to the fact that "forward" is now left. If the drone is facing you, the forward and backward movements are reversed. With a little practice you'll intuitively be able to deal with the controls, but it does take practice. I was proud when I was successfully able to fly around trees, or circle-strafe a standing person while keeping the camera pointed at them.
But still, I crashed. I crashed hard and often. Amazingly, the drone suffered only one instance of a scuffed propeller, and I was able to swap it out in a few minutes. Parrot sells replacement parts and hosts video tutorials that explain how to replace or repair all the major parts. After accidentally slamming it into concrete walls, landing too hard, or even getting attacked by a cat who was tired of being buzzed, the drone was fine. If you ding the hull, you can repair it with tape or buy a replacement for that as well. We were ultimately impressed by how much punishment it could take with no ill effects. It shrugged off crashes that made us wince. The controls can be adjusted and tweaked on the iPhone, giving you some fine control over how you'd like to fly, but you can also simply opt for maximum stability at the expense of maneuverability; it's all a matter of what you're comfortable with. It was interesting to see what happened when my wife called me during a tense flight—the drone simply decreased power and landed softly on the grass.
You can change the display to watch the video feed from the nose of the drone or the downward-facing camera, or you can show both in a sort of picture-in-picture mode. The framerate on the cameras is not spectacular—the 640X480 front-facing camera shoots at 15 FPS while the 176X144 downward-facing camera can shoot up to 60fps—but it gets the job done. Since we weren't able to test any of the augmented reality games, no one who flew it looked down at the screen anyway. Sadly, there is no button to take a screenshot; you must hit the home and power button at the same time on your iPhone to take a photo. Doing this while flying takes some serious skill. And flying is an absolute joy. While turning and doing complicated maneuvers will take hours of practice, it feels great. We passed the iPhone around a group of people and everyone had a blast with it, and even the drone itself was a conversation piece. Watching as it hovers and zooms around is amazing. Having a large area to really cut loose is recommended, even though the internal hull will allow you to practice indoors.
We were told to expect 15 minutes of flying time per 60-90 minute charge, but we were able to get to about 20 minutes depending on how hard we were taxing the drone. It's torture to be having such fun and then have to cool your heels while recharging the battery, so you may want to consider buying an extra battery or two if you plan on picking the drone up. You'll also want to be careful about windy days; the drone can easily be buffeted around if the wind becomes too strong. Since the device is controlled via the iPhone's WiFi, there is also the possibility of interference, and you have a limited range. But luckily, if the connection is dropped the drone knows enough to either sit still and wait for more commands or to land. If any of the propellers hits a solid object, it will likewise switch off, and the propellers are soft enough that unless it hits your eye you won't be injured. To test this I crashed the drone into my son's head while practicing. Because I totally meant to do that.
We've been promised more apps, including games and the ability to fly two drones and have them dog fight each other. Shoot your opponent down and power is cut to the engines and the enemy drone falls to the ground. I'm not sure how many people are going to know someone else who owns one of these, but it still sounds fun. Sadly, this software wasn't available in time for the review. The API is also open and available to anyone who wants to try programming new tricks for the hardware; we hope to see some neat things in this area in the coming months. Yes, $300 is expensive, but you get more than what you pay for. Drone is fun to fly, easy to fix and keep going, and hardy enough that you can open it up and really do some neat things without fear of losing your investment. If the software community embraces it, there will no end to the fun things it can do, but for now we had a great time simply enjoying the way it flew. You can buy the drone now from Brookstone. Ars Technica was provided a unit to test, and it was sent back to the manufacturer after a few weeks of use.
